TC Electronic Monitor Pilot Passive-Monitor Switching Control Station, UK Plug

The TC Electronic Monitor Pilot is a sleek passive monitor control station designed for precise and convenient studio monitoring. Supporting up to three sets of studio monitors and a headphone output, it features an elegant desktop controller with easy master volume and monitor switching. With high-quality passive circuitry, all-analogue signal path, and calibrated outputs via precision trim controls, it ensures accurate audio reproduction. The separated I/O unit keeps cable runs tidy, while its premium aluminium build delivers both durability and a professional studio aesthetic.

Features:

• Multi-monitor switching control station for up to three sets of studio monitors and one set of headphones
• Easy access master volume control in an elegant design with monitor switching controls
• Separated I/O housing and control panel for tidy cable runs and a sleek aesthetic
• High-quality main studio stereo XLR inputs and 1/8" TRS jack input for use with external media devices
• All stereo outputs include independent precision trim pots for calibrated listening
• High-quality passive switching to A/B between monitor sets
• All-analogue signal path retains original audio quality
• High-grade aluminium desktop control housing with visual feedback of the active speaker set
• Extremely easy to set up and use
• Universal wall wart included

Specifications:

• Analogue Inputs: 2 x XLR, balanced
• Aux Inputs: 1/8 " TRS, stereo unbalanced
• Monitor Out 1-3: 2 x XLR, balanced
• Phones Out: 1/4 " TRS, stereo
• Frequency Response: +0/-0.2 dB, 20 Hz to 20 kHz
• Voltage: 100-240 VAC, 50/60 Hz
• Power Consumption: 12 W max.
• Power Supply: 12 V DC, 1000 mA (included)
• Dimensions: 1.5 x 10.3 x 2.8" (39 x 261 x 70 mm)
• Weight: 0.6 kg (1.2 lbs)
