Warm Audio WA-TS Tube Squealer Overdrive Pedal
Tube Squealer is a faithful recreation of three screaming overdrives known for driving tube amps into blissful tonal saturation. Select between authentic 808, TS9, and TS10 circuits, each capturing the legendary Japanese designs that shaped decades of guitar tone. Added modern features include a mix knob for blending clean and driven signals, a pickup-voicing selector for humbuckers or single-coils, and an external voltage booster for extra headroom. With premium analogcomponents, selectable true/buffered bypass, and meticulous hand-testing in Austin, TX, the Tube Squealer delivers classic tube-driving tone with unmatched flexibility.
Features:
- Faithful Recreation Of Three Screaming Overdrives With Added Rig-Ready Features
- Three-Mode, Soft-Clipping, Tube Amp-Driving Overdrive Pedal With Mix Knob, Pickup Voicing Selector, Voltage Booster, & True/Buffered Bypass Selector
- Components: (2x) IC’s (Including JRC4558 Op-Amps), (3x) Discrete Transistors, (2x) JFETs, (4x) Diodes, Switch Cap Voltage Doubler Supply
- Hand tested in Austin, TX
Specifications:
- Controls: Level, Drive, Tone, Mix, Pickup-Voicing Selector, Circuit Selector, Voltage Boost, & Bypass Selector
- Input Sensitivity: 500k Ω
- Output Level (Max): +2.1dBu @9V | +9dBu @18V
- Connections: ¼ Jack Input & Output
- Power: 9v Center-Negative Power
- Power Consumption: 12mA In Standard Mode | 25mA Boosted
- Dimensions: 5.1” (W) x 2.75” (H) x 2.63” (D)
- Weight: 0.45 kg (1 lb)
More Images
Warm Audio WA-TS Tube Squealer Overdrive Pedal
Tube Squealer is a faithful recreation of three screaming overdrives known for driving tube amps into blissful tonal saturation. Select between authentic 808, TS9, and TS10 circuits, each capturing the legendary Japanese designs that shaped decades of guitar tone. Added modern features include a mix knob for blending clean and driven signals, a pickup-voicing selector for humbuckers or single-coils, and an external voltage booster for extra headroom. With premium analogcomponents, selectable true/buffered bypass, and meticulous hand-testing in Austin, TX, the Tube Squealer delivers classic tube-driving tone with unmatched flexibility.
Features:
- Faithful Recreation Of Three Screaming Overdrives With Added Rig-Ready Features
- Three-Mode, Soft-Clipping, Tube Amp-Driving Overdrive Pedal With Mix Knob, Pickup Voicing Selector, Voltage Booster, & True/Buffered Bypass Selector
- Components: (2x) IC’s (Including JRC4558 Op-Amps), (3x) Discrete Transistors, (2x) JFETs, (4x) Diodes, Switch Cap Voltage Doubler Supply
- Hand tested in Austin, TX
Specifications:
- Controls: Level, Drive, Tone, Mix, Pickup-Voicing Selector, Circuit Selector, Voltage Boost, & Bypass Selector
- Input Sensitivity: 500k Ω
- Output Level (Max): +2.1dBu @9V | +9dBu @18V
- Connections: ¼ Jack Input & Output
- Power: 9v Center-Negative Power
- Power Consumption: 12mA In Standard Mode | 25mA Boosted
- Dimensions: 5.1” (W) x 2.75” (H) x 2.63” (D)
- Weight: 0.45 kg (1 lb)
